netty4是2.5.6引入的，2.5.6之前的netty用的是netty3。在dubbo源码中相较于netty3，添加netty4主要仅仅改了两个类：NettyServer，NettyClient。还有就是编解码。
使用方式：
服务端：
1
客户端：
1
一、服务端 - NettyServer
1 package com.alibaba.dubbo.remoting.transport.netty4; 2 3 import com.alibaba.dubbo.common.Constants; 4 import com.alibaba.dubbo.common.URL; 5 import com.alibaba.dubbo.common.logger.Logger; 6 import com.alibaba.dubbo.common.logger.LoggerFactory; 7 import com.alibaba.dubbo.common.utils.ExecutorUtil; 8 import com.alibaba.dubbo.common.utils.NetUtils; 9 import com.alibaba.dubbo.remoting.Channel; 10 import com.alibaba.dubbo.remoting.ChannelHandler; 11 import com.alibaba.dubbo.remoting.RemotingException; 12 import com.alibaba.dubbo.remoting.Server; 13 import com.alibaba.dubbo.remoting.transport.AbstractServer; 14 import com.alibaba.dubbo.remoting.transport.dispatcher.ChannelHandlers; 15 import com.alibaba.dubbo.remoting.transport.netty4.logging.NettyHelper; 16 17 import io.netty.bootstrap.ServerBootstrap; 18 import io.netty.buffer.PooledByteBufAllocator; 19 import io.netty.channel.ChannelFuture; 20 import io.netty.channel.ChannelInitializer; 21 import io.netty.channel.ChannelOption; 22 import io.netty.channel.EventLoopGroup; 23 import io.netty.channel.nio.NioEventLoopGroup; 24 import io.netty.channel.socket.nio.NioServerSocketChannel; 25 import io.netty.channel.socket.nio.NioSocketChannel; 26 import io.netty.util.concurrent.DefaultThreadFactory; 27 28 import java.net.InetSocketAddress; 29 import java.util.Collection; 30 import java.util.HashSet; 31 import java.util.Map; 32 33 public class NettyServer extends AbstractServer implements Server { 34 35 private static final Logger logger = LoggerFactory.getLogger(NettyServer.class); 36 37 private Map channels; // 38 39 private ServerBootstrap bootstrap; 40 41 private io.netty.channel.Channel channel; 42 43 private EventLoopGroup bossGroup; 44 private EventLoopGroup workerGroup; 45 46 public NettyServer(URL url, ChannelHandler handler) throws RemotingException { 47 super(url, ChannelHandlers.wrap(handler, ExecutorUtil.setThreadName(url, SERVER_THREAD_POOL_NAME))); 48 } 49 50 @Override 51 protected void doOpen() throws Throwable { 52 NettyHelper.setNettyLoggerFactory(); 53 54 bootstrap = new ServerBootstrap(); 55 56 bossGroup = new NioEventLoopGroup(1, new DefaultThreadFactory("NettyServerBoss", true)); 57 workerGroup = new NioEventLoopGroup(getUrl().getPositiveParameter(Constants.IO_THREADS_KEY, Constants.DEFAULT_IO_THREADS), 58 new DefaultThreadFactory("NettyServerWorker", true)); 59 60 final NettyServerHandler nettyServerHandler = new NettyServerHandler(getUrl(), this); 61 channels = nettyServerHandler.getChannels(); 62 63 bootstrap.group(bossGroup, workerGroup) 64 .channel(NioServerSocketChannel.class) 65 .childOption(ChannelOption.TCP_NODELAY, Boolean.TRUE) 66 .childOption(ChannelOption.SO_REUSEADDR, Boolean.TRUE) 67 .childOption(ChannelOption.ALLOCATOR, PooledByteBufAllocator.DEFAULT) 68 .childHandler(new ChannelInitializer () { 69 @Override 70 protected void initChannel(NioSocketChannel ch) throws Exception { 71 NettyCodecAdapter adapter = new NettyCodecAdapter(getCodec(), getUrl(), NettyServer.this); 72 ch.pipeline()//.addLast("logging",new LoggingHandler(LogLevel.INFO))//for debug 73 .addLast("decoder", adapter.getDecoder()) 74 .addLast("encoder", adapter.getEncoder()) 75 .addLast("handler", nettyServerHandler); 76 } 77 }); 78 // bind 79 ChannelFuture channelFuture = bootstrap.bind(getBindAddress()); 80 channelFuture.syncUninterruptibly(); 81 channel = channelFuture.channel(); 82 83 } 84 85 @Override 86 protected void doClose() throws Throwable { 87 try { 88 if (channel != null) { 89 // unbind. 90 channel.close(); 91 } 92 } catch (Throwable e) { 93 logger.warn(e.getMessage(), e); 94 } 95 try { 96 Collection channels = getChannels(); 97 if (channels != null && channels.size() > 0) { 98 for (com.alibaba.dubbo.remoting.Channel channel : channels) { 99 try {100 channel.close();101 } catch (Throwable e) {102 logger.warn(e.getMessage(), e);103 }104 }105 }106 } catch (Throwable e) {107 logger.warn(e.getMessage(), e);108 }109 try {110 if (bootstrap != null) {111 bossGroup.shutdownGracefully();112 workerGroup.shutdownGracefully();113 }114 } catch (Throwable e) {115 logger.warn(e.getMessage(), e);116 }117 try {118 if (channels != null) {119 channels.clear();120 }121 } catch (Throwable e) {122 logger.warn(e.getMessage(), e);123 }124 }125 126 public Collection getChannels() {127 Collection chs = new HashSet ();128 for (Channel channel : this.channels.values()) {129 if (channel.isConnected()) {130 chs.add(channel);131 } else {132 channels.remove(NetUtils.toAddressString(channel.getRemoteAddress()));133 }134 }135 return chs;136 }137 138 public Channel getChannel(InetSocketAddress remoteAddress) {139 return channels.get(NetUtils.toAddressString(remoteAddress));140 }141 142 public boolean isBound() {143 return channel.isActive();144 }145 } netty4的写法与netty3有很大不同，下面是netty3：（）
1 /** 2 * 启动netty服务，监听客户端连接 3 */ 4 @Override 5 protected void doOpen() throws Throwable { 6 NettyHelper.setNettyLoggerFactory(); 7 ExecutorService boss = Executors.newCachedThreadPool(new NamedThreadFactory("NettyServerBoss", true)); 8 ExecutorService worker = Executors.newCachedThreadPool(new NamedThreadFactory("NettyServerWorker", true)); 9 ChannelFactory channelFactory = new NioServerSocketChannelFactory(boss, worker, getUrl().getPositiveParameter(Constants.IO_THREADS_KEY, Constants.DEFAULT_IO_THREADS));10 bootstrap = new ServerBootstrap(channelFactory);11 12 final NettyHandler nettyHandler = new NettyHandler(getUrl(), this);13 channels = nettyHandler.getChannels();14 // https://issues.jboss.org/browse/NETTY-36515 // https://issues.jboss.org/browse/NETTY-37916 // final Timer timer = new HashedWheelTimer(new NamedThreadFactory("NettyIdleTimer", true));17 bootstrap.setPipelineFactory(new ChannelPipelineFactory() {18 public ChannelPipeline getPipeline() {19 NettyCodecAdapter adapter = new NettyCodecAdapter(getCodec(), getUrl(), NettyServer.this);20 ChannelPipeline pipeline = Channels.pipeline();21 /*int idleTimeout = getIdleTimeout();22 if (idleTimeout > 10000) {23 pipeline.addLast("timer", new IdleStateHandler(timer, idleTimeout / 1000, 0, 0));24 }*/25 pipeline.addLast("decoder", adapter.getDecoder());26 pipeline.addLast("encoder", adapter.getEncoder());27 pipeline.addLast("handler", nettyHandler);28 return pipeline;29 }30 });31 // bind32 channel = bootstrap.bind(getBindAddress());33 }
二、客户端 - NettyClient
1 package com.alibaba.dubbo.remoting.transport.netty4; 2 3 import com.alibaba.dubbo.common.Constants; 4 import com.alibaba.dubbo.common.URL; 5 import com.alibaba.dubbo.common.Version; 6 import com.alibaba.dubbo.common.logger.Logger; 7 import com.alibaba.dubbo.common.logger.LoggerFactory; 8 import com.alibaba.dubbo.common.utils.NetUtils; 9 import com.alibaba.dubbo.remoting.ChannelHandler; 10 import com.alibaba.dubbo.remoting.RemotingException; 11 import com.alibaba.dubbo.remoting.transport.AbstractClient; 12 import com.alibaba.dubbo.remoting.transport.netty4.logging.NettyHelper; 13 14 import io.netty.bootstrap.Bootstrap; 15 import io.netty.buffer.PooledByteBufAllocator; 16 import io.netty.channel.Channel; 17 import io.netty.channel.ChannelFuture; 18 import io.netty.channel.ChannelInitializer; 19 import io.netty.channel.ChannelOption; 20 import io.netty.channel.nio.NioEventLoopGroup; 21 import io.netty.channel.socket.nio.NioSocketChannel; 22 import io.netty.util.concurrent.DefaultThreadFactory; 23 24 import java.util.concurrent.TimeUnit; 25 26 public class NettyClient extends AbstractClient { 27 28 private static final Logger logger = LoggerFactory.getLogger(NettyClient.class); 29 30 private static final NioEventLoopGroup nioEventLoopGroup = new NioEventLoopGroup(Constants.DEFAULT_IO_THREADS, new DefaultThreadFactory("NettyClientWorker", true)); 31 32 private Bootstrap bootstrap; 33 34 private volatile Channel channel; // volatile, please copy reference to use 35 36 public NettyClient(final URL url, final ChannelHandler handler) throws RemotingException { 37 super(url, wrapChannelHandler(url, handler)); 38 } 39 40 @Override 41 protected void doOpen() throws Throwable { 42 NettyHelper.setNettyLoggerFactory(); 43 final NettyClientHandler nettyClientHandler = new NettyClientHandler(getUrl(), this); 44 bootstrap = new Bootstrap(); 45 bootstrap.group(nioEventLoopGroup) 46 .option(ChannelOption.SO_KEEPALIVE, true) 47 .option(ChannelOption.TCP_NODELAY, true) 48 .option(ChannelOption.ALLOCATOR, PooledByteBufAllocator.DEFAULT) 49 //.option(ChannelOption.CONNECT_TIMEOUT_MILLIS, getTimeout()) 50 .channel(NioSocketChannel.class); 51 52 if (getTimeout() < 3000) { 53 bootstrap.option(ChannelOption.CONNECT_TIMEOUT_MILLIS, 3000); 54 } else { 55 bootstrap.option(ChannelOption.CONNECT_TIMEOUT_MILLIS, getTimeout()); 56 } 57 58 bootstrap.handler(new ChannelInitializer() { 59 protected void initChannel(Channel ch) throws Exception { 60 NettyCodecAdapter adapter = new NettyCodecAdapter(getCodec(), getUrl(), NettyClient.this); 61 ch.pipeline()//.addLast("logging",new LoggingHandler(LogLevel.INFO))//for debug 62 .addLast("decoder", adapter.getDecoder()) 63 .addLast("encoder", adapter.getEncoder()) 64 .addLast("handler", nettyClientHandler); 65 } 66 }); 67 } 68 69 protected void doConnect() throws Throwable { 70 long start = System.currentTimeMillis(); 71 ChannelFuture future = bootstrap.connect(getConnectAddress()); 72 try { 73 boolean ret = future.awaitUninterruptibly(3000, TimeUnit.MILLISECONDS); 74 75 if (ret && future.isSuccess()) { 76 Channel newChannel = future.channel(); 77 try { 78 // Close old channel 79 Channel oldChannel = NettyClient.this.channel; // copy reference 80 if (oldChannel != null) { 81 try { 82 if (logger.isInfoEnabled()) { 83 logger.info("Close old netty channel " + oldChannel + " on create new netty channel " + newChannel); 84 } 85 oldChannel.close(); 86 } finally { 87 NettyChannel.removeChannelIfDisconnected(oldChannel); 88 } 89 } 90 } finally { 91 if (NettyClient.this.isClosed()) { 92 try { 93 if (logger.isInfoEnabled()) { 94 logger.info("Close new netty channel " + newChannel + ", because the client closed."); 95 } 96 newChannel.close(); 97 } finally { 98 NettyClient.this.channel = null; 99 NettyChannel.removeChannelIfDisconnected(newChannel);100 }101 } else {102 NettyClient.this.channel = newChannel;103 }104 }105 } else if (future.cause() != null) {106 throw new RemotingException(this, "client(url: " + getUrl() + ") failed to connect to server "107 + getRemoteAddress() + ", error message is:" + future.cause().getMessage(), future.cause());108 } else {109 throw new RemotingException(this, "client(url: " + getUrl() + ") failed to connect to server "110 + getRemoteAddress() + " client-side timeout "111 + getConnectTimeout() + "ms (elapsed: " + (System.currentTimeMillis() - start) + "ms) from netty client "112 + NetUtils.getLocalHost() + " using dubbo version " + Version.getVersion());113 }114 } finally {115 if (!isConnected()) {116 //future.cancel(true);117 }118 }119 }120 121 @Override122 protected void doDisConnect() throws Throwable {123 try {124 NettyChannel.removeChannelIfDisconnected(channel);125 } catch (Throwable t) {126 logger.warn(t.getMessage());127 }128 }129 130 @Override131 protected void doClose() throws Throwable {132 //can't shutdown nioEventLoopGroup133 //nioEventLoopGroup.shutdownGracefully();134 }135 136 @Override137 protected com.alibaba.dubbo.remoting.Channel getChannel() {138 Channel c = channel;139 if (c == null || !c.isActive())140 return null;141 return NettyChannel.getOrAddChannel(c, getUrl(), this);142 }143 } netty3：
1 protected void doOpen() throws Throwable { 2 NettyHelper.setNettyLoggerFactory(); 3 bootstrap = new ClientBootstrap(channelFactory); 4 // config 5 // @see org.jboss.netty.channel.socket.SocketChannelConfig 6 bootstrap.setOption("keepAlive", true); 7 bootstrap.setOption("tcpNoDelay", true); 8 bootstrap.setOption("connectTimeoutMillis", getTimeout()); 9 final NettyHandler nettyHandler = new NettyHandler(getUrl(), this);10 bootstrap.setPipelineFactory(new ChannelPipelineFactory() {11 public ChannelPipeline getPipeline() {12 NettyCodecAdapter adapter = new NettyCodecAdapter(getCodec(), getUrl(), NettyClient.this);13 ChannelPipeline pipeline = Channels.pipeline();14 pipeline.addLast("decoder", adapter.getDecoder());15 pipeline.addLast("encoder", adapter.getEncoder());16 pipeline.addLast("handler", nettyHandler);17 return pipeline;18 }19 });20 }21 22 protected void doConnect() throws Throwable {23 long start = System.currentTimeMillis();24 ChannelFuture future = bootstrap.connect(getConnectAddress());25 try {26 boolean ret = future.awaitUninterruptibly(getConnectTimeout(), TimeUnit.MILLISECONDS);27 28 if (ret && future.isSuccess()) {29 Channel newChannel = future.getChannel();30 newChannel.setInterestOps(Channel.OP_READ_WRITE);31 try {32 // 关闭旧的连接33 Channel oldChannel = NettyClient.this.channel; // copy reference34 if (oldChannel != null) {35 try {36 if (logger.isInfoEnabled()) {37 logger.info("Close old netty channel " + oldChannel + " on create new netty channel " + newChannel);38 }39 oldChannel.close();40 } finally {41 NettyChannel.removeChannelIfDisconnected(oldChannel);42 }43 }44 } finally {45 if (NettyClient.this.isClosed()) {46 try {47 if (logger.isInfoEnabled()) {48 logger.info("Close new netty channel " + newChannel + ", because the client closed.");49 }50 newChannel.close();51 } finally {52 NettyClient.this.channel = null;53 NettyChannel.removeChannelIfDisconnected(newChannel);54 }55 } else {56 NettyClient.this.channel = newChannel;57 }58 }59 } else if (future.getCause() != null) {60 throw new RemotingException(this, "client(url: " + getUrl() + ") failed to connect to server "61 + getRemoteAddress() + ", error message is:" + future.getCause().getMessage(), future.getCause());62 } else {63 throw new RemotingException(this, "client(url: " + getUrl() + ") failed to connect to server "64 + getRemoteAddress() + " client-side timeout "65 + getConnectTimeout() + "ms (elapsed: " + (System.currentTimeMillis() - start) + "ms) from netty client "66 + NetUtils.getLocalHost() + " using dubbo version " + Version.getVersion());67 }68 } finally {69 if (!isConnected()) {70 future.cancel();71 }72 }73 } 还有就是编解码。
后续会做netty4源码阅读计划。
